PRODUCT DESCRIPTION

Types of steel wire mesh: crimped mesh, welded wire mesh, chain link fence, fence mesh, expanded metal mesh, mine screen mesh, hexagonal mesh.

Steel wire mesh is a general term for woven or welded mesh materials with low carbon steel wire, medium carbon steel wire, high carbon steel wire, stainless steel wire and other materials. The production process includes: ordinary braided type, embossed braided type and spot welding type.

The steel wire mesh is mainly made of steel wire and processed into a mesh shape by professional equipment, so it is called steel wire mesh.

Wire mesh is a necessary building material for building crack prevention and wall insulation.

The steel wire mesh is the skeleton of the cement mortar base surface, and the steel wire mesh or the galvanized wire mesh with the thickness of the steel wire of 16-18 and the mesh of 20-25 mm can be selected.

There are two kinds of metal meshes commonly used in steel mesh: expanded metal mesh (drawn mesh) and steel mesh (woven mesh)

The expanded metal mesh is punched and stretched from a 1.2mm thick steel plate. High strength, strong and durable, it can be directly plastered by nailing the expanded metal mesh independently.

Steel wire mesh is made of fine steel wire or galvanized iron wire woven into a mesh, with different mesh densities and sizes, and the unit is "mesh". It must be used as a foil (cement board, wall, etc.).

It is used for decoration with expanded metal mesh, steel wire mesh, plastering wall mesh, and cement mortar is extruded from the back of the mesh and then fixed, and the cement mortar is required to be fully wrapped to protect the metal mesh from rusting, similar to the protection principle of reinforced concrete. Among them, the expanded metal mesh is painted with anti-rust paint before use.

The material of the steel wire mesh is further expanded, mainly including: long stainless steel wire mesh (low nickel, 302, 304, 316, 316L, etc.), mainly used in chemical enterprises for filtration; manganese steel wire mesh (65 Mn, 75 Mn) etc.), mainly used in cement screen, with oxidative screening; 45# steel wire mesh, mainly ordinary screen. Hot-dip galvanized steel wire mesh, mainly used for external insulation of building exterior walls

Advantages of hot-dip galvanized steel wire mesh: excellent anti-corrosion performance, good durability

High tensile strength, good integrity

Wire mesh technical data:

Process - hot-dip galvanized steel wire mesh   wire diameter mm 0.9±0.04

Mesh size mm 12.7×12.7

Solder joint tensile strength N >65

Galvanized layer g/m2 ≥122

Wire mesh implementation standard: ASTM A 740-1998 JG158-2004 QB/T3897-1999

The varieties of external wall insulation mesh include hot-dip galvanized steel mesh, alkali-resistant glass fiber mesh, etc.

Uses and effects: The exterior wall insulation mesh is mainly used for the exterior walls of general buildings, cast-in-place concrete, high-rise residential buildings, etc., and plays an important structural role in the insulation system. The inner side of the outer wall outer mold to be poured, the outer insulation board and the wall survive at one time, and the insulation board and the wall are combined into one after the mold is removed, thus saving manpower, time and installation costs. The selected hot-dip galvanized steel wire mesh frame polystyrene plate is large, light in weight, easy to construct, and the exterior surface can be used for face tiles, which is easy to operate and can also be constructed in winter.

PRODUCT SERVICE

FACTORY TOUR

Q&A

Q1: Can you send samples?

A: Of course, we can provide customers with free samples and express service around the world.

Q2: What product information do I need to provide?

A: Please provide the width, thickness, surface treatment requirements you need and the quantity you need to buy.

Q3: I am importing wire mesh for the first time, can you help me?

A: Of course, we have an agent to arrange the shipment, and we will do it with you.

Q4: What are the shipping ports?

A: In general, we ship from Shanghai, Tianjin, Qingdao, Ningbo ports, you can specify other ports as needed.

Q5: How about the product price information?

A: The price changes according to the periodic price changes of raw materials, we will give you the best price.

Q6: What are your payment terms?

A: Payment<=1000USD, 100% prepayment. Payment >= USD 1000, 30% T/T in advance, balance before shipment or according to copy of bill of lading or letter of credit at sight.

Q7. Do you provide customized product services?

A: Yes, if you have your own design, we can produce according to your specifications and drawings.

Q8: What certifications do your products have?

A: We have ISO 9001, MTC, third party inspection, such as SGS, BV, etc.
