PRODUCT DESCRIPTION

Stainless steel mesh belts are called by name: stainless steel mesh belts, stainless steel conveyor belts, stainless steel metal conveyor belts, stainless steel metal mesh belts, stainless steel metal conveyor belts, stainless steel transmission belts, stainless steel metal transmission mesh belts, metal spiral mesh belts, and metal turning mesh belts;

Stainless steel mesh belts by industry: conveyor belts on fully automatic equipment such as food processing machinery, glass products, and conveying machinery;

Stainless steel mesh belt by material: A3 low carbon steel mesh belt, 1cr13 mesh belt, 201 mesh belt, 304 mesh belt, ICY18N19Ti mesh belt, 2520 mesh belt, 316 mesh belt, etc.;

Stainless steel mesh belt by shape: herringbone mesh belt, B-shaped mesh belt, diamond mesh belt, horseshoe mesh belt (Great Wall mesh belt), chain conveyor belt, glasses mesh belt, chain plate mesh belt, spherical mesh belt, Chain hook type metal conveyor belt, punch type metal conveyor belt, etc.;

Stainless steel mesh belt by specifications:

Chain Marker-Pitch P--- Chain Rod Pitch P1- Chain Rod Diameter D- Mesh Diameter D1- Mesh Belt Pitch L-Mesh Belt Pitch J

(P)----(p)------(p1)---------(D)-------(D1)-----(L)- -------(J)

C2042--25.40mm--25.40×*section---5~8mm--1.0~1.6mm--3~19mm-----6.35~25.4mm

C2052--31.75mm--31.75×*section---6~10mm-1.2~2.0mm--5~21mm-----6.35~31.75mm

C2062--38.10mm--38.10×*section---8~12mm-1.5~2.0mm--8~21mm-----6.35~38.1mm

C2082--50.80mm--50.80×*section--10~12mm-1.5~3.0mm-10.5~21mm-12.7~50.8mm

C2160--101.6mm--101.6×*section--10~14mm-1.5~4.0mm-10.5~27mm-12.7~50.8mm.

Application of stainless steel mesh belt:

1. Product application range: quick-freezing, flat conveying of baking machinery, screw conveying, cleaning, sterilization, drying, cooling, cooking and other glass machinery annealing, baking, bottle conveying, etc. of food machinery.

2. Transmission of various pipelines.

Stainless steel mesh belts are widely used in:

1. Annealing furnace mesh belts, flower furnace mesh belts, etc. in the glass product industry.

3. Food processing industry, dehydrated vegetables, quick-frozen food, single-freezer pretreatment mesh belt, chain mesh.

4. Powder metallurgy, metal heat treatment, quenching, sintering, brazing, roasting, bright, blackening, bearing, carburizing high temperature furnace mesh belt, baffle mesh belt, coating and drying line conveyor mesh belt, foam nickel reduction production line Mesh belt, washing machine, elevator, dryer, dryer, curing furnace mesh belt. And other conveying process equipment.

Features of stainless steel mesh belt:

The stainless steel mesh belt is a friction-driven machine that transports materials in a continuous manner. Using it, a material conveying process can be formed from the initial feeding point to the final unloading point on a certain conveying line. It can not only carry out the transportation of broken and bulk materials, but also can carry out the transportation of pieces of goods. In addition to pure material transportation, it can also cooperate with the requirements of the technological process in the production process of various industrial enterprises to form a rhythmic assembly line. Therefore, metal mesh belts are widely used in various modern industrial enterprises. It is an indispensable and important accessory in automatic devices and modern automatic assembly lines in various industries.

Stainless steel mesh belt: It has special functions such as flat mesh surface, high strength and hardness, strong corrosion resistance, high tensile strength, good air permeability, not easy to deform, and durable.

PRODUCT SERVICE

FACTORY TOUR

Q&A

Q1: Can you send samples?

A: Of course, we can provide customers with free samples and express service around the world.

Q2: What product information do I need to provide?

A: Please provide the width, thickness, surface treatment requirements you need and the quantity you need to buy.

Q3: I am importing wire mesh for the first time, can you help me?

A: Of course, we have an agent to arrange the shipment, and we will do it with you.

Q4: What are the shipping ports?

A: In general, we ship from Shanghai, Tianjin, Qingdao, Ningbo ports, you can specify other ports as needed.

Q5: How about the product price information?

A: The price changes according to the periodic price changes of raw materials, we will give you the best price.

Q6: What are your payment terms?

A: Payment<=1000USD, 100% prepayment. Payment >= USD 1000, 30% T/T in advance, balance before shipment or according to copy of bill of lading or letter of credit at sight.

Q7. Do you provide customized product services?

A: Yes, if you have your own design, we can produce according to your specifications and drawings.

Q8: What certifications do your products have?

A: We have ISO 9001, MTC, third party inspection, such as SGS, BV, etc.
